The HS2414A is an all in one POS terminal packing in all the peripherals for different applications into one machine

Designed as a solution for the counter space problem, this all in one POS terminal extends the possibility of maximizing sales in a store.

Enquire about the product

System Configuration
Processor	Allwinner A64 Quad Core CPU, 1.20GHz
System Memory	2 GB DDR3
Storage Device	Default 16 GB eMMC + MicroSD slot x 1
Power Supply	12V / 60W
OS Support	Android 7.1
Display &Touch
LCD Display	14" TFT LCD
Resolution	1366 x 768
Touch Function	True-flat PCAP touch with multi-touch support (IP65 on front panel)
I/O & Expansion
Audio	Internal 2W speaker x 1
CR Port	1, control 2 CR via optional Y-cable
Display Port	VGA x 1, 12V support for Posiflex monitors
Extension Slot	M.2 slot x 1
Fingerprint Sensor	Optical type
Lan Port	10/100/1000Mb x1
Serial Port	DB9 x 2, 5V / 12V support on COM 2
Standard USB Port	USB 2.0 x 3
PS/2 Port	Yes
OTG USB	Micro-USB x 1
Built in options
Built-in MSR	Optional Integrated 3 track module (HID/VCOM Selectable)
Built-in Printer	detachable printer w/auto cutter, 250 mm/sec (default.)
Built-in RFID Reader	Optional Integrated, support MIFARE Ultralight and Classic 1K card (HID/VCOM Selectable)
Built-in WIFI	Optional Internal mini-PCIe WIFI module with PIFA antenna
Scanner	2D barcode scanner
4G / LTE	4G / LTE support with full SIM slot
Physical Characteristics
Dimension (W x D x H in mm)	371.5 x 198 x 473
Weight (N.W. in Kg)	5.8
Environmental
Operating Condition	0°C – 50°C, 20%RH – 90%RH (Equipped with SSD)
Storage Condition	-20°C – 70°C, 10%RH – 90%RH
More
iButton	Yes (cannot coexist with Fingerprint Sensor)
** The product information and specifications are subject to change without prior notice
